Siemens NX Nastran 10.0 (x64) | 929 MB


NX Nastran solves structural analysis problems for linear and nonlinear analysis, dynamic response, rotor dynamics,
aeroelasticity and optimization. The NX Nastran 9.0 release further increases the types of solutions you can perform,
along with a number of computational performance and engineering workflow improvements as highlighted by the examples
below:

Discipline and Physical Domain Extension
NX 10.0 - Simulation - Nastran - Discipline and Physical Domain Extension
Speed-dependent bearing properties for rotor dynamics allow you to more realistically simulate bearings in rotating
systems, such as aircraft engines. Properties of the bearing are speed-dependent and support the inherent cross-
directional coupling stiffness and viscous damping.

Greater flexibility to model multi-rotor systems allows you to describe speeds of all rotors independently. This means
you can model multiple rotors to have more complex rotor speed functions that are not simply fixed ratios between each
other.
Frequency-dependent acoustic absorbers characterize absorbing material as fluid with equivalent properties. This
results in a less computationally intensive solution than direct modeling.

Year / Date of Release: 2015
Version: 10.0
Developer: Siemens PLM Automation
Developer website:

Bit depth: 64bit
Language: English
Medicine: Present (Team-SolidSQUAD)
System requirements: Windows 64-bit
